Yuanfengpower 100 Watt Solar Panels With Border 100w 18v Mon

Select high-efficiency monocrystalline silicon solar cells, the power generation efficiency is about 1.2 times that of conventional polysilicon, and the overall area is smaller at the same power.; Using the latest component packaging technology, thinner, lighter, softer and longer life. 2kg (4.4lbs) lighter than ordinary solar glass panels.; The surface is made of PET and treated with a special process, which is more wear-resistant and improves the absorption efficiency of sunlight.; With high light transmittance, safe and reliable, not afraid of high temperature, no danger of burning or explosion.; The junction box adopts IP67 waterproof design, contains bypass diode, and the circuit adopts overcharge and reverse current protection design. Color:100W

Notes for use:
a. This product must not come into contact with highly corrosive substances.
b. It is strictly forbidden to modify, disassemble, drop, and hit the junction box and products by yourself, avoid stepping on the surface and scratching the surface with hard objects during use.
c. A large number of scratches or dirt on the surface of the solar panel may cause the solar cell module to be inefficient, and in severe cases may cause burnout.
d. The suitable ambient temperature range of this product: -20 C-80 C, please do not exceed this range.
e. The solar panel must be installed in an area with good sunlight and no shadow. The long-term work of the solar cell module in the sun with shadow may have the risk of burning.
f. It is forbidden to connect the positive and negative poles of the product together, and it is forbidden to put the product into water or fire, otherwise it will damage the product.
g. The overall power of the photovoltaic module must be less than the rated power of the controller (rated voltage rated current). It is strictly prohibited to overload the controller.
h. The total voltage of the photovoltaic module connected to the controller must be within the photovoltaic input voltage range of the controller.
i. The inverter can only be connected to the battery, not directly to the controller.
Maximum power(Pmax)100W
Output tolerance 3%
Maximum system voltage700V DC
Open circuit voltage(Voc) 21.6V
Short circuit current(Isc)6.11 A
Maximum power voltage(Vmp)18V
Maximum power current(Imp) 5.55A
Cell efficiency21%
Operating temperatureNOCT452
Temperature range-4080
Number of cells36pcs
Weight3100g (6.8Ibs)
Size116053025 mm
Solar cellMonocrystalline silicon
Standard Test Conditions lrradiance 1000w/m2Temperature 25, AM1.5
Packge list:
1 100W solar panel Todos nuestros productos estan en inglés SKU 15092101717
